c8volt ops purge orphan-process-instances

The Problem

Orphan child process instances are hard to delete safely because the operator first has to discover children whose parents are missing, freeze that exact candidate set, validate the process-instance delete plan, and then run deletion without accidentally widening the scope during execution.

The Promise

c8volt ops purge orphan-process-instances discovers orphan child process instances, freezes their keys, runs the shared process-instance delete preview, and either reports the plan with --dry-run or deletes only after confirmation. It supports deterministic JSON output and Markdown or JSON audit reports.

In Action

The recording previews the orphan process-instance purge before deleting anything, then runs the purge, confirms the prompt, writes an audit report, and opens the first report section. It shows the normal purge rhythm: freeze the candidate set, inspect the plan, confirm the mutation, then keep the evidence.

Generic command shape:

# read-only: preview orphan cleanup
c8volt ops purge orphan-process-instances --dry-run

# destructive: deletes the frozen orphan process-instance family scope after confirmation
c8volt ops purge orphan-process-instances --state completed --limit 25 --report-file orphan-purge.md

Use When

• cleaning up child process instances whose parents are missing
• narrowing orphan cleanup by process-definition, date, state, parent, or incident filters
• previewing the affected process-instance trees before deletion
• writing an audit report for a maintenance cleanup

Command At A Glance

# read-only: preview orphan cleanup
c8volt ops purge orphan-process-instances --dry-run

# destructive: deletes only the bounded orphan scope selected at command start
c8volt ops purge orphan-process-instances --state completed --limit 25 --report-file orphan-purge.md

Built From Lower-Level Commands

This is the conceptual flow. The implemented command calls c8volt services directly.

c8volt get pi --orphan-children-only --keys-only [filters...]
c8volt delete pi -

Implemented selection controls include process-definition filters, --pd-key, date ranges, --batch-size, --limit, --parent-key, --state, --incidents-only, and --no-incidents-only. When the discovery filters include --bpmn-process-id, c8volt validates the visible process-definition selector before freezing orphan process-instance keys. Execution controls include --workers, --no-worker-limit, --fail-fast, --no-wait, --force, --automation, --json, --report-file, and --report-format.

Workflow

discover orphan child process instances
        |
        v
freeze candidate orphan keys
        |
        v
build shared cancel/delete dry-run plan
        |
        v
resolve roots and affected family keys
        |
        +--> --dry-run: report preview, mutate nothing
        |
        v
block non-final affected scope unless --force is set
        |
        v
confirm, auto-confirm, or automation-confirm
        |
        v
delete planned root process-instance trees
        |
        v
write optional audit report

Dry Run

--dry-run performs discovery and delete-plan validation only. Human output shows candidate orphan count and the delete preview: orphan candidates, affected process instances, roots, and any additional process instances due to dependencies. Verbose output lists candidate keys.

When no orphan candidates are found, the command reports a skipped preview and exits successfully with outcome planned.

Real Execution

Without --dry-run, the command first plans the same frozen scope. If the run is not already implicitly confirmed, it prompts with the candidate and affected counts. If the plan includes affected process instances that are not in a final state, mutation is blocked unless --force is supplied.

Deletion submits root process-instance trees through the existing process-instance deletion service. --no-wait returns after accepted deletion requests; otherwise the command reports confirmed deletion when all reports are OK.

Reports

Reports use schema version ops.orphan-process-instances.v1. They include command metadata, selection filters, discovered candidate keys, delete plan root and affected keys, deletion item status, confirmation/no-wait flags, errors, and outcome.

Report format is inferred from --report-file unless --report-format markdown|json is supplied.

Failure And Safety Notes

• --dry-run never submits deletion requests.
• --automation is supported and implicitly confirms supported prompts.
• --force is required when the planned affected scope contains non-final process instances.
• Existing report files are preserved unless the run is already confirmed for mutation.
• --keys-only is supported as an output mode for the discovered orphan keys.

Related Commands

• ops purge orphan-process-instances
• get process-instance
• delete process-instance
