c8volt ops purge all-process-definitions
The Problem
Deleting process definitions is not just a resource cleanup. A selected process-definition version can still have active process instances, so the operator needs discovery, process-instance impact planning, force gating, deletion execution, and an audit report in one workflow.
The Promise
c8volt ops purge all-process-definitions discovers candidate process-definition versions with get pd-style selectors, freezes their keys, previews delete impact, blocks active process-instance scope unless --force is supplied, and deletes the selected definitions only after confirmation. The full process-definition purge workflow is supported for Camunda 8.9 and newer, where c8volt can request process-definition history deletion through the Camunda resource deletion endpoint.
Discovery pages through all matching process definitions by default. --batch-size controls how many process definitions are inspected per discovery page, and --limit is the explicit cap for the frozen purge scope. Human output, JSON output, and Markdown reports show whether discovery completed or was user-limited.
In Action
The recording previews process-definition purge impact before deleting anything, then runs the purge with --force, confirms the prompt, writes an audit report, and opens the first report section. It shows the key safety point for this workflow: process definitions are selected first, but c8volt still plans and reports process-instance impact before mutation.
Generic command shape:
# read-only: preview selected process definitions and process-instance impact
c8volt ops purge all-process-definitions --bpmn-process-id <bpmn-process-id> --latest --dry-run
# destructive: deletes the selected process definition scope after confirmation
c8volt ops purge all-process-definitions --bpmn-process-id <bpmn-process-id> --latest --force --report-file process-definition-purge.md
Use When
- cleaning up old process-definition versions by BPMN process ID, key, version, version tag, or latest scope
- previewing process-instance impact before deleting process definitions
- deleting process-definition versions and their affected instances in a controlled maintenance window
- producing a Markdown or JSON audit report for process-definition cleanup
Command At A Glance
# read-only: preview selected process definitions and affected instances
c8volt ops purge all-pds --bpmn-process-id <bpmn-process-id> --latest --dry-run
# destructive: deletes the selected process definition and affected scope after confirmation
c8volt ops purge all-process-definitions --key <process-definition-key> --force --report-file process-definition-purge.md
Built From Lower-Level Commands
This is the conceptual flow. The implemented command calls c8volt services directly.
c8volt get pd [process-definition filters...]
c8volt delete pd --key <candidate-process-definition-key>
The command supports --key, --bpmn-process-id, --pd-version, --pd-version-tag, and --latest for candidate discovery. --batch-size changes request size only and does not stop discovery. Use --limit N when the purge scope should intentionally contain at most N matching process definitions. When --bpmn-process-id is set, c8volt validates visible process-definition matches before impact planning, confirmation, or deletion. Execution controls include --workers, --no-worker-limit, --fail-fast, --no-wait, --force, --automation, --json, --report-file, and --report-format.
Workflow
discover candidate process definitions
|
v
freeze unique process-definition keys
|
v
preview delete-pd impact
|
v
count affected and active process instances
|
+--> --dry-run: report preview, mutate nothing
|
v
block active process-instance impact unless --force is set
|
v
confirm, auto-confirm, or automation-confirm
|
v
delete selected process definitions
|
v
write optional audit report
Dry Run
--dry-run discovers matching process definitions and runs the delete preview. Human output shows candidate process-definition count, grouped BPMN/version impact when available, and a delete preview with affected process-instance count. If active instances are in scope, output reports that --force is required before deletion.
Dry-run output includes discovery user-limited when --limit stops discovery. Normal completed paging is shown only with --verbose.
Verbose output lists normal completed discovery paging, candidate process-definition details, and planned keys.
Real Execution
Without --dry-run, the command plans the same frozen candidate set before mutation. If the run is interactive, it prompts with candidate and affected counts. If active process instances are affected and --force is not set, the command fails before submitting deletion.
Deletion uses the existing process-definition deletion service. With --force, affected active process instances may be canceled according to existing delete process-definition behavior. --no-wait returns after accepted deletion requests.
Reports
Reports use schema version ops.all-process-definitions.v1. They include selection filters, latest-only scope, candidate process-definition keys and details, duplicate candidates, delete-plan items, affected and active process-instance counts, deletion items, no-wait/force/fail-fast flags, notices, errors, and final outcome.
Report format is inferred from --report-file unless --report-format markdown|json is supplied.
Failure And Safety Notes
- Full process-definition purge is supported from Camunda 8.9 onward. On earlier configured Camunda versions, c8volt fails before discovery or deletion because those endpoints do not support full process-definition history deletion.
--pd-versionmust be positive when supplied.--workersmust be positive when supplied.- Active process-instance impact blocks mutation unless
--forceis set. --latestnarrows candidate discovery to latest matching process definitions.- Existing report files are preserved unless the run is already confirmed for mutation.
